wallnode
The Smart Audio Solution for Small Spaces
AVAILABLE TO ORDER
wallnode is a PoE-powered, wall-mounted audio panel designed for smaller spaces such as spas, boutiques, huddle rooms, and dressing rooms.
This compact device provides ambient audio and emergency messaging, delivering exceptional sound quality along with intuitive user controls for volume adjustment and channel selection.
Being PoE-powered and compatible with the Q-sys ecosystem, wallnode seamlessly integrates into your existing setup, providing you with an enhanced and controlled audio experience.
Maximum continuous output power of 10W.
Up to 10 audio channels.
Emergency paging always comes through thanks to its override feature, making the wallnode a safer choice compared to traditional potentiometer-controlled volume attenuators.
Set-up local audio processing using built-in DSP to match your speaker.
Designed to fit into a standard dual-gang box, Wallnode offers an easy-to-deploy audio solution tailored to the unique needs of small spaces.
Trust your audio devices following latest IT and physical security standards.
Optional AES256-GCM encryption for AES67.
Seamless integration with Q-sys.
Key highlights
Emergency paging
In the event of emergency messaging or fire alarms, wallnode can override user volume and channel settings.
Third-party compatibility
Can be used as part of Q-SYS paging system.
Security & high quality
Receive high-quality audio over AES67 for integration into your audio infrastructure.
Intuitive control
Use two rotary encoders and LED bars to adjust volume and select from up to 10 audio channels.
| Description | PoE powered networked wall controller with built in 10W audio amplifier |
| Audio | Frequency response: 20 hz – 20 kHz, 4/8 Ohm speaker Maximum continuous output power @ 8 Ohm speaker: 8W, 0.1% THD+N Maximum continuous output power @ 4 Ohm speaker: 10W, 0.1% THD+N Signal to noise ratio 108 dB |
| Connectivity | 1 x LAN RJ45 1000 Mbps with PoE |
| DSP | 15+ Component library API library |
| User Interface | 10 Led volume indicator Volume rotary encoder 10 Led channel select indicator Channel select rotary encoder Web-based configuration interface Cloud-connected |
| Security | Secure boot Encrypted firmware Secure enclave chip Optional AES256-GCM encryption for AES67 |
| Compatibility | Q-SYS |
| Environmental | Operating temperature range 32 °F – 122 °F (0 °C – 50 °C) Storage temperature range 14 °F to 140 °F (-10 °C – 60 °C) |
| Power | IEEE 802.3af power over Ethernet (PoE) |
| Dimensions | 111 mm (W) x 42 mm (D) x 107 mm (H) US 2-gang box compatible 400 g w |
| Accessories | Mounting kit |
Specifications
Visit the Download Center for product resources
